Baumalight TNS336‑S3604 Trencher
Authorized Baumalight Dealer
Ensuring quality backed by full manufacturer warranty & support.
The Baumalight TNS336‑S3604 2014 Trencher Model is a heavy‑duty hydraulic trenching attachment engineered for use on skid steer loaders and compact tractors. With a maximum trenching depth of 36 inches and a 4‑inch wide Rock & Cup Tooth chain, this model provides efficient, clean trenching for utilities, irrigation systems, gas lines, electrical conduit and landscaping work. Its sealed planetary direct‑drive system delivers hydraulic torque directly to the digging sprocket, eliminating the maintenance challenges associated with roller chain drives. Rugged construction, precise control and dependable performance make the TNS336‑S3604 ideal for contractors, landscapers and construction professionals who need a reliable trencher on compact equipment.
Features & Benefits
- 36″ Maximum Trenching Depth: Ideal for utility installation, irrigation trenches, cable and gas line work.
- 4″ Cutting Width: Narrow trench profile with Rock & Cup Tooth chain for clean cuts in soil and moderate rock.
- Sealed Planetary Drive: Direct hydraulic torque to the chain reduces maintenance and improves reliability.
- Carrier Compatibility: Designed for skid steers and compact tractors with 30–55 HP engines and 2,000–5,000 lb operating weight.
- Hydraulic Flow Range: Optimized for standard auxiliary flows (~10–20 GPM on skid steers and ~14–22 GPM on tractors).
- Crumb Scraper Bar: Spring‑loaded scraper keeps the trench floor clean by dragging loose material back into the chain.
- Solid Steel Nose: Reinforced nose with dual tapered bearings resists leverage and force during digging.
- Durable Construction: Heavy‑duty steel frame and chain assembly stands up to tough ground conditions.
Specifications
| Specification | Detail |
|---|---|
| Model | Baumalight TNS336‑S3604 Trencher |
| Attachment Type | Hydraulic skid steer / compact tractor trencher |
| Maximum Trenching Depth | 36″ |
| Trenching Width | 4″ |
| Chain Type | Rock & Cup Tooth chain |
| Drive System | Sealed planetary direct hydraulic drive |
| Hydraulic Flow Requirement | Skid Steer: ~10–20 GPM; Tractor: ~14–22 GPM |
| Carrier Weight Compatibility | ~2,000–5,000 lbs |
| Recommended Horsepower | 30–55 HP |
| Mounting | Standard skid steer quick‑attach (tractor 3‑point optional) |
| Crumb Scraper | Spring‑loaded dirt scraper for clean trench floor |
| Special Features | Reinforced steel nose with dual bearings |
| Use | Utility, irrigation, gas, and electrical line trenching |
| Construction | Heavy‑duty steel frame and chain assembly |
