Loflin Fabrication Mat Grapple
Authorized Loflin Fabrication Dealer
Ensuring quality backed by full manufacturer warranty & support.
The Loflin Fabrication Mat Grapple is a robust, versatile attachment engineered for skid steer loaders and compatible machinery to efficiently lift, transport, and secure heavy mats, metal pipe bundles, lumber, and other bulky materials. Built with heavy‑gauge American steel and reinforced construction, this grapple is designed to withstand demanding jobsite conditions while delivering dependable performance and long service life.
Featuring an adjustable top clamp with multiple mounting positions and a wide grapple opening, this tool provides a secure grip and flexibility needed for professional material handling tasks. Whether moving rig mats on oilfield sites, transporting construction materials, or organizing heavy stock, the Loflin Fabrication Mat Grapple enhances productivity while reducing manual labor and load‑shifting hazards.
Designed to integrate seamlessly with standard skid steer hydraulics and optional fork configurations, this grapple is a versatile choice for contractors, land managers, and equipment operators looking to maximize their machine’s utility with a rugged, precision‑built attachment.
Features & Benefits
- Heavy‑Duty Construction – Built with 4″ square tubing, 1/4″ sidewalls, and reinforced gussets for long‑lasting durability on tough lifting jobs.
- Adjustable Top Clamp – Four mounting positions deliver a secure grip and adaptable handling on uneven or irregular loads.
- Hydraulic Control – Powerful 2″ bore x 10″ stroke cylinder gives smooth, precise movement and secure clamping for large material bundles.
- Wide Grapple Opening – Up to 58″ of grapple travel accommodates large mats, pipe, and bulky materials with ease.
- Fork‑Compatible Options – Optional 42″, 48″, 60″, and 72″ forks and adjustable pin locations expand functionality for pallet or material handling needs.
- High Lift Capacity – Supports up to 10,000 lbs, making it ideal for heavy‑duty site work and industrial applications.
- Jobsite Ready Hardware – Equipped with quality Parker hoses, fittings, and couplers to minimize setup time.
Specifications
| Specification | Details |
|---|---|
| Product Name | Loflin Fabrication Mat Grapple |
| Applications | Heavy material handling, mat & pipe lifting, construction & landscaping |
| Overall Width | 60 ¾″ |
| Grapple Width | 18″ |
| Overall Height | 36 ½″ |
| Material Thickness | 4″ square tubing, 1/4″ side wall |
| Grapple Tine Thickness | 1/2″ |
| Gussets | 3/8″ |
| Bolt‑On Side Plates | 3/8″ |
| Max Grapple Opening | 58″ |
| Hydraulic Cylinder | 2″ bore x 10″ stroke (3200 psi) |
| Lift Capacity | 10,000 lbs |
| Weight | 850 lbs |
| Options | 42″, 48″, 60″ & 72″ forks; adjustable pin locations |
| Part Number | 0090101060 |
| Build Origin | American Made – Loflin Fabrication |
